Vertical Pipeline Booster Inline Pump

Single-stage pipeline centrifugal pump is a pump capable of transporting liquid from a low container to a high container. It is usually composed of a motor, a pump body and an inlet and outlet pipe. The working principle is that the motor drives the impeller in the pump body to rotate, transferring energy to the liquid, so that the liquid obtains energy and increases its pressure and speed, and finally transmits the liquid to the high container through the import and export pipe.

Characteristics

1. The structure is vertical withthe same sizes ofinlet andoutlet in the same centerline.It canbe installed in thepipeline like the valve. The pump has the compac structure and good appearance andlow construction cost andoccupieslittle place. It can also be used outdoorswith protective cover.
2. Impeller isinstalledin the extended shaft of electric motor and so the axial size is small. The structure of the pump is very compact. The pump is matched reasonably with bearing of electric motor. Radial and axialload are well balanced during the operation. So it mak es sure that the pump can operate sta bly with littlevibration and noise.
3. Shaft seal adopts mechanical seal or the combination ofmechanical seal. The mechani cal seal is made from hard alloy mat erial and adopts titanium alloy sealing ring or middling high temperature re sistance mechanical seal. So it has the best w earable seal and can prolong the life of m echanical seal.
4. Convenient to install and maintain. Only loose the nut of pump seat to draw out all rotors It neednot disassemble pipeline system.
5. Parallel conne ctionand in series can be chosen for different flowrate and head.
6. It can be installed horizontally and vertically as different pipeline system.

Applications

Chemical industry: Pipeline pumps can be used to transport a variety of chemical raw materials, such as liquid chemicals, solvents, coatings, etc. During chemical reactions, pipeline pumps can also be used to transport reaction materials from one device to another.
Petroleum industry: Pipeline pumps can be used to transport petroleum products, such as gasoline, diesel, lubricating oil, etc. In gas stations, pipeline pumps can be used to transport oil from storage tanks to the tank of the vehicle.
Water treatment industry: Pipe pumps can be used to transport liquids from one place to another. For example, in water treatment, pipeline pumps can be used to transport water from one pool to another, or to add chemicals to the water.
Food industry: Pipe pumps can be used to transport food from one place to another. For example, in food processing, pipeline pumps can be used to transport food ingredients such as juice, drinks, cheese, etc., from one container to another.
Construction industry: Pipeline pumps can be used to transport building materials such as building paint, cement and mortar. In construction sites, pipeline pumps can be used to transport building materials from one place to another, improving construction efficiency.
Field irrigation: Pipe pumps can be used to transport water from low water sources to high fields for field irrigation. In arid areas, piped pumps can also be used to draw water from groundwater for irrigation.
